VEGAMET 861 Series Level Controller - NoWall 1 Voltage Input 230 V AnalogueMET861.XXX1C
MET861.XXX1C - VEGAMET 861 Series Level Controller - NoWall 1 Voltage Input 230 V Analogue
305-19-950
MET861.XXX1C
Manufacturer:Vega
New to us
Image is for illustrative purposes only. Please refer to product description.
MET861.XXX1C - VEGAMET 861 Series Level Controller - NoWall 1 Voltage Input 230 V Analogue
305-19-950
MET861.XXX1C
Manufacturer:Vega
Product specifications
Select attributes and click search to find other products that match your specification
Downloads
Datasheets
Product Information
Legislation and compliance
RoHS
Conforms
REACH Regulation No SVHC
Article Information
Current Rating: 5 A Hazardous Area Certification: No IP Rating: IP65 Input Type: Voltage Maximum Operating Temperature: 60 °C Maximum Supply Voltage: 230 V Minimum Operating Temperature: -40 °C Mount Type: Wall Number of Inputs: 1 Number of Outputs: 7 Output Type: Analogue Overall Depth: 76 mm Overall Length: 200 mm Overall Width: 136 mm Probe Voltage: 27 V Product Type: Level Controller Series: VEGAMET 861 Standards/Approvals: EAC|cULus|UL|CE Terminal Type: M20
Previous Article Number
30519950
Additional information
Country of origin Germany (DE)
Manufacturer Vega
Gross weight (incl. package) 2200 Gram
Dimensions (incl. package) 265 x 195 x 155 MM
Customs number 8537109899
UNSPSC (v5.03) 41111938
